Máy Phân Tích Oxy - The Servomex 1800 Analyser


Product code:

Product Description:


Product details:

The Servomex 1800 analyser is a stable, accurate and highly specific oxygen analyser for safe areas.

Designed for safe area oxyge

Designed for safe area oxygen analysis

Low maintenance and re-calibration requirements

Range of alarm outputs to aid integration with other systems

Easy to set up and operate

Special versions for solvent bearing samples

Special high flow rate cell option



Specification





Gases Measured:

O2

PERFORMANCE

Technology:

Range:

Intrinsic Error (accuracy): Linearity:

Repeatability:

Response time (T90)

Zero drift/ week:

Span drift/ week:

SIGNAL OUTPUTS

Analogue:

 Alarms:

              Concentration

             Sample flow fail





PHYSICAL

Dimensions:(W x D x H)

Weight:

Hazardous area

Classification:

Ingress Protection:

Mounting:



Paramagnetic transducer

0-100% O2 <0.2% of reading or 0.05% O2

<0.05% O2

<0.1% of reading or 0.05% O2

4 to 8 seconds

<0.05% O2

<1% of reading or 0.05% O2



One 4-20 mA, isolated & one 0-1V dc, non-isolated. Ranges selectable from

0 - 2.5, 5, 10, 25 and 100% O2

Two volt free changeover relays rated 250Vac/3A  or 28Vdc (non inductive)

maximum and 5V/10mA ac/dc minimum

One volt free changeover relay rated 250Vac/3A  or 28Vdc (non inductive)

maximum and 5V/10mA ac/dc minimum





448mm x 229mm x 235 mm / 17.6” x 9” x 9.25”

26 kg / 57 lbs



Non-Hazardous Areas only

IP 66 / NEMA 4X

Wall or Panel
